Description

Features/Benefits

  • Ideal for drilling anchor and fixing holes into concrete and masonry from 4 to 22 mm in diameter
  • Impact-stop for drilling in wood, steel, ceramic and screwdriving applications  Features/Benefits
  • Mechanical clutch eliminates sudden high-torque reaction should the bit jam
  • Rounded ergonomic industrial design allows easy and comfortable handling in any application
  • Improved sealing for maximum protection from dust ingress ensuring long tool life

 Technical Specification

  • Power Input – 710 Watts
  • Power Output – 590 Watt
  • Impact energy (EPTA 05/2009) 2.0 J
  • No Load Speed –  0-1550 rpm
  • Blows per Minute – 0-5680 bpm
  • Length – 330 mm
  • Height – 210 mm
  • Width – 75 mm
  • Weight – 2.5 kg
  • Hand/Arm Vibration – Hammer drilling into concrete 13.6 m/sý
  • Uncertainty K 1 (Vibration) – 1.5 m/sý
  • Hand/Arm Vibration – Drilling into metal <2.5 m/sý
  • Uncertainty K 3 (Vibration) –  1.5 m/sý
